1140V Ckj5 AC Vacuum Contactor (CKJ5-63-80A)
Welcome to our factory! We are the leading manufacturer of the 1140V Ckj5 AC Vacuum Contactor (CKJ5-63-80A) and provide top quality products to meet your needs.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
CKJ5-63-80A
Transport Package
Standard Export Package
Trademark
MANYEE
Origin
China
HS Code
8535900090
Production Capacity
200000PCS/Year

Product Description




CKJ5 series AC Vacuum Contactor is designed for long-distance making and breaking in circuit, frequency starting and controlling AC motor in the power system with AC 50 Hz-60Hz, rated operating voltage to 1140V. It also can be formed with thermal relay and all kinds of protection apparatus, as electromagnetic starter, especially applies to explosion electromagnetic starter and all sorts of power control equipment. It may apply to the department of mine, metallurgy, petroleum, chemical industry, power, communication transportation and so on.



Main technical parameter

Model Rated Voltage Rated Current Main contact parameters
Frequency voltage (V) (RMS)

Main Electric Circuit
Main Electric Circuit Control electric circuit (A) contact distance(mm) contact overtravel(mm) contact pressure(mm) Main Electric Circuit Auxiliary circuit Control electric circuit
CKJ5-80/1140 1140 36,110,220,380 80 1.8±0.2 >1 30±5 4200 2500 2000
CKJ5-125/1140 1140 36,110,220,380 125 1.8±0.2 >1 30±5 4200 2500 2000
CKJ5-160/1140 1140 36,110,220,380 160 1.8±0.2 >1 30±5 4200 2500 2000
CKJ5-250/1140 1140 36,110,220,380 250 2±0.2 >1.5 80±10 4200 2500 2000
CKJ5-400/1140 1140 36,110,220,380 400 2+0.5/0 >1.5 120±20 4200 2500 2000
CKJ5-630/1140 1140 36,110,220,380 630 2+0.5/0 >1.5 190±20 4200 2500 2000
CKJ5-800/1140 1140 36,110,220,380 800 2+0.5/1 >1.5 190±20 4200 2500 2000
CKJ5-1000/1142 1140 36,110,220,380 1000 2+0.5/2 >1.5




  1140V Ckj5 AC Vacuum Contactor (CKJ5-63-80A)
